Description
-
- Multi - Size (Inch / cm)
- 23.6" / 59.82 cm
- Multi - Panel Type
- Wide Viewing Angle
-
- Multi - Color Gamut (CIE1931)
- 72%
- Multi - Color Bit
- 8bit (6bit+FRC)
-
- Multi - Color Depth (Number of Colors)
- 16.7M
- Multi - Pixel Pitch(mm)
- 0.38175x0.38175
-
- Multi - Aspect Ratio
- 16:09
- Multi - Resolution
- 1366x768
-
- Multi - Brightness (Typ.)
- 250 cd/m2
- Multi - Contrast Ratio (Original)
- 1000:01:00
-
- Multi - Contrast Ratio (DFC)
- 5M:1
- Multi - Response Time_Typ. (GTG)
- 14ms
-
- Multi - Viewing Angle(CR≥10)
- R/L 178 (Typ.), U/D178 (Typ.)
- Multi - Surface Treatment(Glare/non Glare)
- Hard coating(3H), Anti-glare
-
- Signal Input - D-Sub
- Yes
- Signal Input - DVI-D
- NO
-
- Signal Input - Composite
- Yes
- Signal Input - S-Video
- No
-
- Signal Input - Component
- No
- Signal Input - HDMI (Ver.)
- Yes (HDMI1.3)
-
- Signal Input - DisplayPort (Ver.)
- No
- Signal Input - SCART
- No
-
- Signal Input - CI Slot
- No
- Signal Input - USB (Ver.)
- Yes (USB2.0)
-
- Signal Input - [ Jack Location ]
- Rear/Side
- Audio Input - RCA
- Yes
-
- Audio Input - PC Audio In
- No
- Audio Input - Mic In
- No
-
- Audio Input - [ Jack Location ]
- Rear
- Audio Output - RCA
- Yes
-
- Audio Output - Headphone Out
- No
- Audio Output - Speaker Out
- No
-
- Audio Output - Optical Out
- No
- Audio Output - [ Jack Location ]
- Rear
-
- Tuner Input - Analog
- PAL Multi
- Tuner Input - [ Jack Location ]
- Rear
-
- Network - LAN
- No
- Network - Wi-Fi
- No
-
- Network - Bluetooth
- No
-
- Type
- Internal
- Audio output
- 5W x 2
-
- Input/Output - Type (w/ Watt)
- Adapter ( 32W)
- Input/Output - Input
- 100~240V
-
- Input/Output - Output(for Speaker)
- No
- Consumption - Normal On(Typ.)
- 30W
-
- Consumption - DC Off(Max)
- 0.5W
-
- D-sub(H-Frequency)
- 30kHz~69kHz
- D-sub(V-Frequency)
- 56Hz~61Hz
-
- HDMI - H-Frequency
- 30kHz~69kHz
- HDMI - V-Frequency
- 56Hz~61Hz
-
- PC (D-sub)
- 1366x768
- Video - HDMI
- 480p, 576p 720p, 1080i, 1080p
-
- Video - Composit
- 480i/576i
-
- Key Number (Power Key Included)
- 1 Key
- Key Type
- JOYSTICK KEY
-
- LED Color(On mode)
- Off
- LED Color(Standby)
- Red
-
- [ Key Location ]
- Bottom
-
- Number of Language
- 18 Language (English/French/Spanish/Portuguese/Russian/Thai Malay/Indonesian/Hebrew/Farsi/Arabic/Kurd Vietnam, Hindi, Marathi, Telugu, Bengali, Tamil)
-
- General Function - sRGB
- No
- General Function - DDC/CI
- No
-
- General Function - HDCP
- Yes
- General Function - Intelligent Auto
- Yes
-
- General Function - Remote Control
- Yes
- General Function - Key Lock
- No
-
- General Function - Plug & Play
- DDC2B
- Accessibility - EPG
- No
-
- Accessibility - Teletext
- Yes
- Accessibility - Caption
- No
-
- Accessibility - Audio Description (Visual Impaired)
- No
- Special Function - Flicker Safe
- Yes
-
- Special Function - Eye Comfort Mode
- Yes
- Special Function - Gaming Mode
- No
-
- Special Function - Cinema Mode
- No
- Special Function - Divx HD player (USB Media Player)
- Yes (Video, Music, Picture)
-
- Special Function - USB Auto Play
- Yes
- Special Function - VoiceOn (Audio Guidance)
- No
-
- Special Function - PIP
- No
- Special Function - Time Machine Ready
- No
-
- Special Function - Bluetooth Audio
- No
- Special Function - MaxxAudio
- No
-
- Special Function - Screen Share (Wi-Fi Mirroring)
- No
- Special Function - Smart Energy Saving
- Yes
-
- Special Function - Motion Eye Care
- Yes
- Special Function - USB Game (Download)
- No
-
- Special Function - Built-in Game
- Yes
(Egg Catcher, Space Wars, Cookie Cookie, Jungle Hunter, Bubble Pot)
- Special Function - DLNA
- No
-
- Picture - Picture Mode
- Vivid, Standard, Cinema, Soccer, Game
- Picture - F-engine
- No
-
- Picture - Triple XD engine
- No
- Picture - ARC-PC
- 16:9, 4:3
-
- Picture - ARC-Video
- 16:9 - ATV, AV, RGB, HDMI Just Scan – HDMI Original - ATV, AV, HDMI 4:3 - ATV, AV, RGB, HDMI 14:9 - ATV, AV, HDMI Zoom - ATV, AV, HDMI Cinema Zoom - ATV, AV, HDMI
- Sound - SRS
- No
-
- Sound - Virtual surround
- No
- Sound - Dolby Surround
- No
-
- Sound - AVL (Auto Volume)
- Yes
- Sound - Equalizer
- No
-
- Time / Clock - Auto / Manual Clock
- Yes (Manual Only)
- Time / Clock - On/ Off Time
- Yes
-
- Time / Clock - Sleep Timer
- Yes
- Time / Clock - Auto Off / Auto Sleep
- Yes
-
- Hotel mode - Hotel Mode
- Yes
- Hotel mode - TV Linker
- No
-
- Hotel mode - RS232C
- No
- Hotel mode - USB Cloning
- No
-
- Front
- Black Glossy
- B/Cover
- texture
-
- Stand
- Black Glossy
- Base
- Black Glossy
-
- Base Detchable
- Detachable
- Tilt(Angle)
- No
-
- Swivel(Angle)
- No
- Height(mm)
- No
-
- Pivot
- No
- Dual Hinge
- No
-
- Dimension - Set (with Stand)
- 556.0 x 146.3x 387.3
- (W*D*H) - Set (without Stand)
- 556.0 x 53.1 x 345.2
-
- (mm) - Box
- 700 x 402 x 126
- Wall Mount
- 75*75
-
- Weight - Set (with Stand)
- 3.4
- (Kg) - Set (without Stand)
- 3.2
-
- Box
- 4.4
- Stuffing - Pallet(20ft/40ft/40ft HC)
- 704 / 1408 / 1672
